BlueOptics Lenovo A51N kompatibilný BlueLAN 10GBASE-CR pasívny SFP+ Direct Attach kábel, 2 metre, AWG30

The BlueOptics A51N-BL is a high-performance, passive Direct Attach Cable (DAC) designed for 10 Gigabit Ethernet connectivity. This SFP+ to SFP+ twinax copper cable is fully compatible with Lenovo A51N and other standard SFP+ ports, offering a cost-effective and reliable solution for short-range interconnects in data centers and enterprise networks.

Advantages

This passive DAC cable delivers low power consumption (<0.1W) and zero latency, making it ideal for high-density environments. Its pre-terminated design eliminates the need for separate transceivers, reducing cost and complexity. The AWG30 wire gauge ensures flexibility for easy cable management, while the 2-meter length is perfect for rack-to-rack or server-to-switch connections.

Suitable for

• Data center interconnect (top-of-rack to server)
• High-performance computing (HPC) clusters
• Enterprise networking (Cisco, Juniper, Arista, Mellanox, HP, Dell, IBM, Lenovo)
• Server-to-switch and switch-to-switch links

Key specifications

• Product Type: Direct Attach Cable (DAC)
• Data Rate: 10 Gbps
• Technology Standard: 10GBASE-CR
• Cable Type: Twinax Copper
• Active/Passive: Passive
• Connector Type (End A): SFP+
• Connector Type (End B): SFP+
• Cable Length: 2 Meter
• Wire Gauge: AWG30
• Hot-Swappable: Yes
• MSA Compliant: Yes
• Impedance: 100 Ohm
• Power Consumption: < 0.1W
• Operating Temperature: 0°C to 70°C (32°F to 158°F)

Recommendations

For optimal performance, ensure your SFP+ ports are compatible with passive DAC cables. This cable is designed for short distances up to 2 meters and is not suitable for long-haul applications. Always verify compatibility with your specific networking equipment.
