Eaton 215644 svorka zbernice, rovná, konektor samec, meď, biela, 10 mm², 63 A

Rated for 63 A and accepting 10 mm² conductors, this Eaton busbar terminal clamp delivers a secure, straight, male connection for busbar systems in electrical distribution boards.

Overview

The Eaton 215644 is a busbar terminal clamp designed for straight, male (pin) connection to busbars. It features a screw terminal for conductor connection and is constructed with copper contact material and a white plastic housing. The clamp is intended for use with Eaton xPole busbar systems and is suitable for electrical distribution boards.

What stands out

• Straight, male (pin) design for direct busbar connection
• Rated current of 63 A and rated voltage of 400 V AC
• Accepts conductors up to 10 mm² cross-section
• Copper contact material for reliable conductivity
• White plastic housing for insulation and identification
• Clip-on mounting to busbar, no tools required
• Complies with IEC/EN 60947-7-1

Technical details

• Product type: Busbar terminal clamp
• Design: Straight
• Connection type (busbar): Pin (male)
• Conductor connection type: Screw terminal
• Rated conductor cross-section: 10 mm²
• Rated current (In): 63 A
• Rated voltage (Ue): 400 V AC
• Contact material: Copper
• Housing material: Plastic
• Housing colour: White
• Number of poles: 1
• Compatibility: Eaton xPole busbar systems
• Mounting method: Clip-on to busbar
• Protection degree: IP20
• Standards: IEC/EN 60947-7-1
• Application: Electrical distribution boards

Our verdict

A reliable and straightforward busbar connection solution from Eaton, built to handle 63 A with a 10 mm² conductor capacity.
