Eaton FAZ-C3/1 istič typu C 3A 1-pólový 6kA 278551

The Eaton FAZ-C3/1 stands out with its precise Type C tripping characteristic, making it ideal for protecting circuits with moderate inrush currents such as lighting and socket outlets. Its compact 1-module width saves space on the DIN rail without compromising performance.

Highlights

• 1-pole miniature circuit breaker with 3 A rated current
• Type C tripping curve handles moderate inrush currents
• 6 kA rated switching capacity for reliable short-circuit protection
• Compact 1 TE (17.5 mm) width for efficient panel space usage
• Screw terminals accept solid or stranded conductors from 1 to 25 mm²

In daily use

Installation is straightforward on standard DIN rail, and the IP20 terminal protection ensures safe wiring. The breaker operates reliably across a wide temperature range from -25 to +75 °C, suitable for various environments. With a mechanical endurance of 20,000 operations, it offers long service life in residential and commercial installations.

Full specifications

• Number of poles: 1
• Rated current: 3 A
• Tripping characteristic: Type C
• Rated voltage: 230/400 V AC
• Rated switching capacity (Icn): 6 kA
• Frequency: 50/60 Hz
• Mounting type: DIN rail
• Degree of protection (terminals): IP20
• Degree of protection (front): IP40
• Terminal type: Screw terminals
• Terminal capacity: 1-25 mm²
• Energy limiting class: 3
• Overvoltage category: III
• Pollution degree: 2
• Standards compliance: IEC/EN 60898-1
• Operating temperature range: -25 to +75 °C
• Storage temperature range: -40 to +80 °C
• Mechanical endurance: 20,000 operations
• Electrical endurance: 10,000 operations
• Module width: 1 TE (17.5 mm)

Final note

A dependable choice for circuit protection where precise tripping and compact design are required.
