Eaton T0-4-8344/I1/SVB vačkový vypínač, 4-pólový, 20 A, 690 V, 3 polohy, predná montáž, čierny rukoväť 207163

This Eaton cam switch stands out with its robust 4-pole design and 20 A rating, making it suitable for demanding industrial control circuits. The T0-4-8344/I1/SVB offers three switching positions with a 90° switching angle, providing precise control in a compact 48 x 48 mm front plate.

Highlights

• 4-pole cam switch for versatile circuit control
• Rated operational current: 20 A at 690 V AC
• Three switching positions with 90° angle
• Front mounting with IP65 protection
• Screw terminals for secure wiring

In daily use

The switch is designed for front mounting and features a black rotary handle. Its IP65 front protection ensures reliable operation in dusty or damp environments. The switching program 8344 defines the contact configuration, allowing for tailored control of motors and other loads.

Full specifications

• Switch type: Cam switch / rotary switch
• Number of poles: 4
• Rated operational current: 20 A
• Rated operational voltage: 690 V AC
• Number of switching positions: 3
• Switching angle: 90°
• Mounting type: Front mounting
• Actuator type: Rotary handle
• Actuator colour: Black
• Front plate dimensions: 48 x 48 mm
• Degree of protection (front): IP65
• Terminal type: Screw terminals
• Rated impulse withstand voltage: 6 kV
• Rated short-circuit current: 1 kA (conditional, with fuse)
• Rated power (AC-23A, 400 V): 5.5 kW
• Standards compliance: IEC/EN 60947, VDE 0660
• Ambient operating temperature: -25 to +50 °C
• Mechanical life: > 0.5 x 10^6 operations
• Electrical life (AC-21A): > 0.2 x 10^6 operations

Final note

The Eaton T0-4-8344/I1/SVB is a reliable choice for industrial switching applications requiring high current capacity and robust construction.
