Nástenná skriňa EFB Elektronik 691706VGR.40

The EFB Elektronik 691706VGR.40 wall mounted rack is a 6U cabinet designed for indoor network and equipment installation where floor space is limited. With a compact footprint of 600 mm width and 400 mm depth, and a height of 330 mm, this grey metal enclosure provides a secure mounting environment for switches, patch panels and similar 19" compatible devices. The cabinet supports up to 50 kg of distributed load and includes a key lock for controlled access. Its IP20 rating makes it suitable for protected indoor environments such as server rooms, communication closets and office equipment zones.

Advantages

The rack’s 6U capacity and 19" compatibility allow standard networking hardware to be installed without modification, while the compact 600×400 mm footprint conserves wall and floor space. A key lock gives a basic level of physical security to prevent unauthorized access. The IP20 protection rating ensures that the enclosure is appropriate for dust-protected indoor installations. The neutral grey finish integrates with typical office and technical environments and enables organized cable routing and device placement.

Suitable for

• Mounting network switches and patch panels in small server rooms
• Housing telecommunication equipment in office communication closets
• Securing 19" devices in retail or branch office installations
• Edge computing or monitoring hardware where space is limited

Key specifications

• Rack capacity: 6U (19" compatible)
• Width: 600 mm
• Depth: 400 mm
• Height: 330 mm
• Maximum weight capacity: 50 kg (distributed)
• International Protection rating: IP20
• Colour: Grey

How to use

Mount the rack on a suitable load-bearing wall using appropriate anchors and fixings for the wall material, ensuring the installation supports the maximum distributed weight. Install 19" equipment using the front mounting rails, aligning devices to the 6U positions and securing them with compatible mounting hardware. Route and secure cabling to avoid strain on connectors and maintain ventilation clearances. Use the integrated key lock to control physical access to installed equipment.

Recommendations

For safe and reliable operation, distribute equipment weight evenly across the mounting rails and avoid exceeding the 50 kg distributed load. Install the cabinet in a clean, dry indoor environment consistent with IP20 protection, and ensure proper ventilation and cable management to prevent overheating of installed devices.
