SFP transceiver BlueOptics BTI-MGBIC-GSX-DD-LC-BO 1250 Mbit/s 850 nm

The BlueOptics BTI-MGBIC-GSX-DD-LC-BO is an SFP transceiver module for fiber-optic network links. It supports a data rate up to 1250 Mbit/s and transmits at a wavelength of 850 nm. The module is housed in a metal casing, requires a 3.3 V supply and has a compact form factor with a weight of approximately 20 g. Designed for use with standard SFP ports, it uses an LC duplex optical connector and is intended for short-range multimode fiber links.

Advantages

The transceiver combines a compact SFP form factor with a robust metal enclosure, offering straightforward integration into network equipment that accepts SFP modules. With a 1250 Mbit/s maximum throughput and 850 nm wavelength, it is compatible with established 1.25 G optical interfaces. Low weight and standard electrical requirements (3.3 V) make it a practical option for switch, router or media-converter installations where LC duplex multimode connections are required.

Suitable for

Key specifications

How to use

Install the BlueOptics SFP transceiver into an available SFP slot on compatible network hardware while the device is powered down or following the host vendor's hot-swap procedure. Connect an LC duplex multimode fiber patch cable to the module's connector, observing correct transmit/receive orientation. Power the host device and verify link status using the switch or router management interface. For equipment that supports digital diagnostics, enable or query the DDM/DOM functions if available to monitor operational parameters.

Recommendations

Use this 850 nm SFP in multimode fiber environments for short-reach links according to the host equipment specifications. Verify compatibility with the target hardware and ensure the fiber type, connector type and transceiver wavelength match the rest of the link. Follow the vendor guidance for ESD protection during handling and store spare modules in anti-static packaging.
